DC 600V 2P Solar Mini Circuit Breaker Battery Switch 80A 125A 100A DC MCB for Photovoltaic PV S

DC 600V 2P Solar Mini Circuit Breaker Battery Switch 80A 125A 100A DC MCB for Photovoltaic PV System
Specifications:
DC Circuit Breaker: TXBD1-125
Frame Degree Rated Current: 125A
Pole: 2P
Rated Operating Voltage: DC12-600V
Rated Current In: 80A/100A/125A
Rated Insulation Voltage: Ui 800VDC
Ultimate Breaking Capacity: lcu 10KA
Curve Type C
Mechanical Life: 20000 times
Electric Life: 10000 times
ote:
1.Due to the light and screen difference, the item’s color may be slightly different from the pictures.
2.Please allow 1-3cm differences due to manual measurement.
Package Includes:
1x Voltage Protector Socket
